Electronics-Salon Slim Right Angle D'SUB DB62HD Female Header Breakout Board Module, Terminal Block DSUB Connector.
Product Description
Electronics-Salon Slim Right Angle D'SUB DB62HD Female Header Breakout Board Module, Terminal Block DSUB Connector.
- This item has been assembled, and electrical test passed.
- Pitch 3.81mm/0.15" screw terminal block.
- FR-4 fiber glass PCB.
- Rated voltage: 60V, Rated current: 500mA / per pin.
- Operating Temperature: -20ºC to 50ºC
DB62HD Female Slim Right Angle D'SUB Breakout Board.
This item has been assembled, and electrical test passed.
Pitch 3.81mm/0.15" screw terminal block.
FR-4 fiber glass PCB.
Rated voltage: 60V, Rated current: 500mA / per pin.
Operating Temperature: -20ºC to 50ºC
Terminal block:
Wire range 26 to 16AWG.
Strip length 5mm.
Screws - M2,steel,Cr3+ Zn plated.
Pin header and Cage - Brass.
Technical Specifications
